Hello World

Summary: In this tutorial i am going to show you how to create cross platform Project by just 1 line of Text in CygWin & work on it !

Requirement: Python for running the Script

Detail: Let’s start by creating Cross platform Project

Let’s open CYGWIN

Enter :

1. cd C:/Downloads/cocos2d-x-2.2.2/cocos2d-x-2.2/tools/project-creator

2. ./create_project.py -project Hello -package com.developerhouse.hello -language cpp

Let me explain the Parameters

–project Project Name

–package Package Name

–language  Language Name (cpp | lua | javascript)

Press Enter it will create the Project in Cocos2dx Root Directory /Projects/ Project_Name (Hello in our Case)

if you have followed our last tutorial then you know how to Import the project & Run it

if not then Please read it

https://developerhouse.com/blog/?p=6

Open Hello Project folder

now you know proj.[android|blackberry|tizen|win32] Folder

let’s talk about Classes & Resources Folder

Classes folder includes your C++ Classes & Headers file (Codes)

Resources folder includes your assets (Graphics,Sound,Shaders,JSON Files,XML Files or any other type)

Open project in Visual Studio or in any other IDE

Open AppDelegate.cpp

#include "AppDelegate.h"
#include "HelloWorldScene.h"

USING_NS_CC;

AppDelegate::AppDelegate() {

}

AppDelegate::~AppDelegate()
{
}

bool AppDelegate::applicationDidFinishLaunching() {
    // initialize director
    CCDirector* pDirector = CCDirector::sharedDirector();
    CCEGLView* pEGLView = CCEGLView::sharedOpenGLView();

    pDirector->setOpenGLView(pEGLView);

    // turn on display FPS
    pDirector->setDisplayStats(true);

    // set FPS. the default value is 1.0/60 if you don't call this
    pDirector->setAnimationInterval(1.0 / 60);

    // create a scene. it's an autorelease object
    CCScene *pScene = HelloWorld::scene();

    // run
    pDirector->runWithScene(pScene);

    return true;
}

// This function will be called when the app is inactive. When comes a phone call,it's be invoked too
void AppDelegate::applicationDidEnterBackground() {
    CCDirector::sharedDirector()->stopAnimation();

    // if you use SimpleAudioEngine, it must be pause
    // SimpleAudioEngine::sharedEngine()->pauseBackgroundMusic();
}

// this function will be called when the app is active again
void AppDelegate::applicationWillEnterForeground() {
    CCDirector::sharedDirector()->startAnimation();

    // if you use SimpleAudioEngine, it must resume here
    // SimpleAudioEngine::sharedEngine()->resumeBackgroundMusic();
}

Red Color Stroke -> CCScene

Green Color Stroke -> CCLayer

Blue Color Stroke -> CCSprite

you can add many CCLayer in CCScene 1 for background ,1 for HUD etc… etc..

Line 28 get Pointer of HelloWorld scene function which is returning a CCScene

Line 31 using our SharedDirector run the HelloWorld::scene()

Line 38 CCDirector::sharedDirector()->stopAnimation(); //Stop the animation when game pause

Line 46 CCDirector::sharedDirector()->startAnimation(); // Run it again when game resumes

_________________________________________________________________

The HelloWorldScene class is sub class of CCLayer

Before we move to code let me explain some Data types

CCSize -> holds two floating point Numbers think it as width and height

CCPoint -> holds two floating point Numbers think it as x and y

ccp -> use it to set CCPoint values // ccp(0,0);

Delete the content of HelloWorldScene to this code according to me by default the code is not easy to understand as a complete beginner

#include "HelloWorldScene.h"

USING_NS_CC;

CCScene* HelloWorld::scene()
{
    // 'scene' is an autorelease object
    CCScene *scene = CCScene::create();

    // 'layer' is an autorelease object
    HelloWorld *layer = HelloWorld::create();

    // add layer as a child to scene
    scene->addChild(layer);

    // return the scene
    return scene;
}

// on "init" you need to initialize your instance
bool HelloWorld::init()
{
    //////////////////////////////
    // 1. super init first
    if ( !CCLayer::init() )
    {
        return false;
    }

    CCSize visibleSize = CCDirector::sharedDirector()->getVisibleSize();
    CCPoint origin = CCDirector::sharedDirector()->getVisibleOrigin();

    // add "HelloWorld" splash screen"
    CCSprite* pSprite = CCSprite::create("HelloWorld.png");

    // position the sprite on the center of the screen
    pSprite->setPosition(ccp(visibleSize.width/2 + origin.x, visibleSize.height/2 + origin.y));

    // add the sprite as a child to this layer
    this->addChild(pSprite, 0);

    return true;
}

Line 3 defined as using namespace cocos2d (Short keyword)

Line 5-18 static scene function which is returning pointer of cocos2d::CCScene*

Line 8 create new CCScene by CCScene::create();

Line 11 create new HelloWorld Layer by HelloWorld::create();

Line 14 add the HelloWorld Layer as child to CCScene by scene->addChild(layer); //the add child method is gonna used many times when you add sprite ,CCrenderTexture etc. etc.

Line 17 reutnr that CCScene which added HelloWorld layer to the scene

Line 21-77 initialize function named init()  return boolean value it’s a Virtual function

Line 25-28 CCLayer::init() call init method of CCLayer if it’s false then return false exit method

Line 30 get Visible size of OpenGL View in CCSize data type CCSize holds two float values like width & height

Line 31 get Visible origin point of OpenGL View in CCPoint data type CCPoint holds two float values like x & y

Line 34 create a new Sprite with the file name which is in Resources folder

Line 37 set Position of the Sprite which is made in 34 by create a new CCPoint using ccp the Position will be center

Line 40 add the sprite as a child of Layer the second parameter is z-index (Hope you knwo what it is if you don’t then no worries it’s like the layer index which will be on top of that layer
just like we do in photoshop or illustrator we drag and drop the layer to the top of it if you set z-index 0 it will top on -1 if you set it 1 then it will be top on 0 Simple)

_______________________________________

This is the end of Hello World Tutorial hope you liked it if you did not then please post in comments what you did not like and what i can improve
we will go more advance step by step

Here is the Project Hello Classes just replace them with the project you created in Classes folder (I have not uploaded the full project because it will let you do some work of  creating your own project OR saving my time for 9 MB project uplaod :D)
https://www.dropbox.com/s/gu64thsadl32wqf/Classes.rar
